Plastic Recycling Machine One Stage
Performance and Characteristics
This machine is suitable for regeneration and granulation of waste plastics,as HDPE,LDPE,and PP, ABS, etc. It is equipped with quick motor-operated filter-screen-replacing unit and automatic temperature control. The granulating crusher uses adjustable speed synchronistically. The unit is easy to operate, with a high output, steady performance, and favorable economic benefit.
Main Technical Variables:
Model |
SJ-90B |
SJ-100B |
SJ-110B |
SJ-120B |
||
Diameter of Screw Stem |
90mm |
100mm |
110mm |
120mm |
||
L:D |
20:1 |
20:1 |
20:1 |
20:1 |
||
Speed of Screw |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
||
Gearbox |
173 |
173 |
180 |
200 |
||
Motor Power |
22kw |
30kw |
30kw |
37kw |
||
Output |
70kg/h |
900kg/h |
120kg/h |
135kg/h |
||
Water Tank Length) |
2500mm Stainless |
|||||
Screen changer |
Hydraulic for both screw |
|||||
Screen changer hole |
6mm |
|||||
Die head hole(Alloy Metal) |
4mm |
|||||
Cutter Knife |
Hobbing Cutter |
|||||
Cutter Motor |
2.2kw |
2.2kw |
3kw |
3kw |
||
Machine Weight |
1800kg |
2000kg |
2200kg |
2500kg |
||
Overail Dimensions |
5.5*1.5*1.1m |
5.9*1.3*1.2m |
6*1.35*1.3m |
6.2*1.4*1.3m |
1, Machine Details: Gearbox and Loader
2, Machine Details: Die head and Hydraulic Screen Changer
3, Machine Details: Main Extruder
4,Dry blower:high speed type, 0.75kw.
5, Machine Details: Wire connection and Electric Box
6 Cutting knife and Final Product
